內
容 |
|
最大荷重(Capacity) |
200kgf (2KN)
|
|
測試行程 (
Stroke) |
150mm |
|
圓柱的長(Column
Length) |
550mm |
|
圓柱的間隔(Column
Distznce) |
有效210mm |
|
測試速度(Test Speed) |
5~80mm/min•5段 |
|
行程檢出方式(Displace
Detect) |
光學尺Linear Gauge |
|
行程計測表示(Displace
Display) |
0~30mm |
|
載物台尺寸(Table
Size) |
200mmψ |
|
驅動機構(Feed
System) |
Precise Ball
Screw |
|
馬達(Motor) |
DC伺服馬達 |
|
本體重量(Weight)
|
41kg |
|
外觀尺寸(Dimensions)
|
W900xH355xD335mm
|
|
電源(Power) |
AC100V/AC220V
|
|
|
| |
| |
|
|
|
|
 |
|
|
|
|
|
